    Ford Ranger

    2014 Ford Ranger XL 2.2 HI-RIDER (4x2) Pricing and Spec

    From

    $17,500

    excl. on-roads

    Overview

    The 2014 Ford Ranger XL 2.2 HI-RIDER (4x2) is a rear-wheel drive cab chassis that was released to the Australian market on 244th September 2011 classified as a PX. The Ford Ranger is regarded as a c/chas built in Thailand with prices from a dealer as a used car starting at $17,500.

    The Ford Ranger is a rear-wheel drive 2 door with 2 seats, powered by a 2.2L DIESEL TURBO 4 engine that has 110 kW of power (at 3700 rpm) and 375 Nm of torque (at 1500 rpm) via a Six-speed Manual. Ford claims the Ranger XL 2.2 HI-RIDER (4x2) uses 7.6L/100km of Diesel in the combined city and highway cycle while putting out 203g of CO2. It has a 80L fuel tank, meaning it should be able to travel 1053km per full tank.

    The Ford Ranger measures 1800mm (70.9 inches) in height, 5110mm (201.2 inches) in length, 1850mm (72.8 inches) in width with a 3220mm (126.8 inches) wheelbase that brings about a total of 1672kg (3686.1 lbs) of unladen weight. The Ranger XL 2.2 HI-RIDER (4x2) comes standard with 215/70 R16 front tyres and 215/70 R16 rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first. It has a 36 month, 100km warranty.

    The 2014 Ford Ranger XL 2.2 HI-RIDER (4x2) has a 232mm ground clearance with a 3500kg braked and 750kg unbraked towing capacity. It has a final gear ratio of 3.55.

    The Ford Ranger has received a 5 star rating from ANCAP. The VIN number can be found on the Centre Of Chassis Frame and the compliance plate is located on the Lower Driver Side B-Pillar. An example VIN number would be similar to 6PF#MBGE0#P123456.

    Best For
    Work
    Family
    Long distance
    Awards
    '23
    Ute of the Year
    Best Ute Overall
    Warranty
    3Years
    or
    100,000 km
    ANCAP Safety Rating
    Fuel Efficiency
    80 L1053 km
    C/CHAS
    DIESEL
    2.2L
    REAR WHEEL DRIVE
    6 MT
    2
    2

    Pros

    • Punchy and refined V6 diesel
    • Surprisingly fuel efficient
    • Benchmark driving experience

    Cons

    • Lacking some wow factor
    • Expensive compared with more enticing Sport grade
    • No wireless phone charger

    Dimensions

    1800mm
    1850mm
    5110mm

    The dimensions shown above are for the base model.

    Specifications

    TypeDIESEL TURBO F/INJ
    Size (cc)2198
    Size (L)2.2L
    InductionDIESEL TURBO 4
    CamshaftDUAL OVERHEAD CAM
    Valves/Ports per Cylinder16
    Power110kW
    Power RPM3700
    Torque375Nm
    Torque RPM1500
    Bore Stroke-
    Compression Ratio15.7

    Transmission6 SP MANUAL
    Final Gear Ratio3.55
    Suspension Front-
    Suspension Rear-
    Steering MechanismRACK & PINION - POWER ASSISTED
    DriveREAR WHEEL DRIVE

    Fuel Combined (L/100km)7.6
    Fuel Urban (L/100km)0
    Fuel Extra Urban (L/100km)0
    Tank Size (L)80
    Fuel TypeDIESEL
    e10 Compatibleunknown
    CO2 Combined203
    CO2 Urban-
    CO2 Extra Urban-

    Brake FrontDISC - VENTILATED
    Brake RearDRUM
    Tyre Front215/70 R16
    Tyre Rear215/70 R16
    Front Rim Size6.5x16
    Rear Rim Size6.5x16

    Vehicle Height (mm)1800
    Vehicle Length (mm)5110
    Vehicle Width (mm)1850
    Ground Clearance (mm)232
    Wheelbase (mm)3220
    Turning Circle (m)12.7
    Unladen Weight (kg)1672
    Gross Combined Weight (kg)0
    Gross Vehicle Weight (kg)3200
    Track Front-
    Track Rear-
    Towing Capacity Brake (kg)3500
    Towing Capacity Unbraked (kg)750

    Compliance Plate LocationLower Driver Side B-Pillar
    Country Of OriginTHAILAND
    Number of Doors2
    Seats2
    Service Interval KMs15
    Service Interval Months12
    VIN LocationCentre Of Chassis Frame
    VIN Number6PF#MBGE0#P123456
    Warranty KMs100
    Warranty Months36
    Discontinued Date2015-07-31

    ANCAP Rating5
    Euro Air Pollution Standard-
