Overview
The 2017 Ford Transit 410L LWB 12 SEAT is a rear wheel drive Bus that was released to the Australian market on 12th January 2016 classified as a VO MY17.25. The Ford Transit is regarded as a light bus built in United Kingdom with prices from a dealer as a used car starting at $31,500.
The Ford Transit is a rear wheel drive 3 door with 12 seats, powered by a 2.2L Diesel Turbo 4 Cylinder engine that has 114 kW of power (at 3500 rpm) and 385 Nm of torque (at 1600 rpm) via a 6 Speed Manual. It has a 100L fuel tank.
The Ford Transit measures 2547mm (100.3 inches) in height, 5981mm (235.5 inches) in length, 2094mm (82.4 inches) in width with a 3750mm (147.6 inches) wheelbase that brings about a total of 2674kg (5895.2 lbs) of unladen weight. The Transit 410L LWB 12 SEAT comes standard with 235/65 R16 front tyres and 235/65 R16 rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first. It has a 36 month, 100km warranty.
The 2017 Ford Transit 410L LWB 12 SEAT has a 154mm ground clearance with a 2500kg braked and 750kg unbraked towing capacity. It has a final gear ratio of 3.150.
The VIN number can be found on the Driver Side Front Wheel Arch and the compliance plate is located on the Pass Side Front Floor. An example VIN number would be similar to WF0HXXTTGHFK12345.
Dimensions
The dimensions shown above are for the base model.
Specifications
| Type | Turbo Common Rail Diesel Injection |
|---|---|
| Size (cc) | 2198 |
| Size (L) | - |
| Induction | Diesel Turbo 4 Cylinder |
| Camshaft | DUAL OVERHEAD CAM |
| Valves/Ports per Cylinder | 16 |
| Power | 114kW |
| Power RPM | 3500 |
| Torque | 385Nm |
| Torque RPM | 1600 |
| Bore Stroke | 86x94.6 |
| Compression Ratio | 15.50 |
| Transmission | 6 Speed Manual |
|---|---|
| Final Gear Ratio | 3.150 |
| Suspension Front | anti roll bar, macpherson strut, independent |
| Suspension Rear | leaf spring, gas pressurised shock absorber |
| Steering Mechanism | RACK & PINION - POWER ASSISTED |
| Drive | RWD |
| Fuel Combined (L/100km) | - |
|---|---|
| Fuel Urban (L/100km) | - |
| Fuel Extra Urban (L/100km) | - |
| Tank Size (L) | 100 |
| Fuel Type | diesel |
| e10 Compatible | - |
| CO2 Combined | 196 |
| CO2 Urban | - |
| CO2 Extra Urban | - |
| Brake Front | DISC - VENTILATED |
|---|---|
| Brake Rear | DISC |
| Tyre Front | 235/65 R16 |
| Tyre Rear | 235/65 R16 |
| Front Rim Size | 6.5x16 |
| Rear Rim Size | 6.5x16 |
| Vehicle Height (mm) | 2547 |
|---|---|
| Vehicle Length (mm) | 5981 |
| Vehicle Width (mm) | 2094 |
| Ground Clearance (mm) | 154 |
| Wheelbase (mm) | 3750 |
| Turning Circle (m) | 13.3 |
| Unladen Weight (kg) | 2674 |
| Gross Combined Weight (kg) | 5500 |
| Gross Vehicle Weight (kg) | 4100 |
| Track Front | - |
| Track Rear | - |
| Towing Capacity Brake (kg) | 2500 |
| Towing Capacity Unbraked (kg) | 750 |
| Compliance Plate Location | Pass Side Front Floor |
|---|---|
| Country Of Origin | United Kingdom |
| Number of Doors | 3 |
| Seats | 12 |
| Service Interval KMs | 15 |
| Service Interval Months | 12 |
| VIN Location | Driver Side Front Wheel Arch |
| VIN Number | WF0HXXTTGHFK12345 |
| Warranty KMs | 100 |
| Warranty Months | 36 |
| Discontinued Date | 31/08/2017 |
| ANCAP Rating | - |
|---|---|
| Euro Air Pollution Standard | - |
