Overview
The 2018 Foton View Cs2 S is a rear wheel drive 2 Door Van that was released to the Australian market on 6th January 2018 classified as a K1 NA. The Foton View Cs2 is regarded as a van built in China with prices from a dealer as a used car starting at $17,500.
The Foton View Cs2 is a rear wheel drive 2 door with 2 seats, powered by a 2.8L Diesel Turbo 4 Cylinder engine that has 105 kW of power (at 3600 rpm) and 320 Nm of torque (at 1600 rpm) via a 5 Speed Manual. Foton claims the View CS2 S uses 9.4L/100km of diesel in the combined city and highway cycle while putting out 0g of CO2. It has a 76L fuel tank, meaning it should be able to travel 809km per full tank.
The Foton View Cs2 measures 2285mm (90.0 inches) in height, 5380mm (211.8 inches) in length, 1920mm (75.6 inches) in width with a 3110mm (122.4 inches) wheelbase that brings about a total of 2090kg (4607.7 lbs) of unladen weight. The View CS2 S comes standard with 195 R15C-106R front tyres and 195 R15C-106R rear tyres. It requires a service every 12 months or 20,000 km, whichever comes first. It has a 36 month, 100km warranty.
The 2018 Foton View Cs2 S has a 190mm ground clearance
The VIN number can be found on the RHS - Lower A-Pillar and the compliance plate is located on the Pass Side Front Floor. An example VIN number would be similar to LVAC2ZBB2GS000520.
Dimensions
The dimensions shown above are for the base model.
Specifications
| Type | Turbo Diesel Direct Injection |
|---|---|
| Size (cc) | 2780 |
| Size (L) | - |
| Induction | Diesel Turbo 4 Cylinder |
| Camshaft | SINGLE OVERHEAD CAM |
| Valves/Ports per Cylinder | 16 |
| Power | 105kW |
| Power RPM | 3600 |
| Torque | 320Nm |
| Torque RPM | 1600 |
| Bore Stroke | 94x100 |
| Compression Ratio | 16.90 |
| Transmission | 5 Speed Manual |
|---|---|
| Final Gear Ratio | 0.000 |
| Suspension Front | double wishbone, independent |
| Suspension Rear | leaf spring, rigid axle |
| Steering Mechanism | RACK & PINION - POWER ASSISTED |
| Drive | RWD |
| Fuel Combined (L/100km) | 9.4 |
|---|---|
| Fuel Urban (L/100km) | - |
| Fuel Extra Urban (L/100km) | - |
| Tank Size (L) | 76 |
| Fuel Type | diesel |
| e10 Compatible | - |
| CO2 Combined | - |
| CO2 Urban | - |
| CO2 Extra Urban | - |
| Brake Front | DISC - VENTILATED |
|---|---|
| Brake Rear | DRUM |
| Tyre Front | 195 R15C-106R |
| Tyre Rear | 195 R15C-106R |
| Front Rim Size | 6x15 |
| Rear Rim Size | 6x15 |
| Vehicle Height (mm) | 2285 |
|---|---|
| Vehicle Length (mm) | 5380 |
| Vehicle Width (mm) | 1920 |
| Ground Clearance (mm) | 190 |
| Wheelbase (mm) | 3110 |
| Turning Circle (m) | 0.0 |
| Unladen Weight (kg) | 2090 |
| Gross Combined Weight (kg) | - |
| Gross Vehicle Weight (kg) | 3400 |
| Track Front | - |
| Track Rear | - |
| Towing Capacity Brake (kg) | - |
| Towing Capacity Unbraked (kg) | - |
| Compliance Plate Location | Pass Side Front Floor |
|---|---|
| Country Of Origin | China |
| Number of Doors | 2 |
| Seats | 2 |
| Service Interval KMs | 20 |
| Service Interval Months | 12 |
| VIN Location | RHS - Lower A-Pillar |
| VIN Number | LVAC2ZBB2GS000520 |
| Warranty KMs | 100 |
| Warranty Months | 36 |
| Discontinued Date | 31/10/2020 |
| ANCAP Rating | - |
|---|---|
| Euro Air Pollution Standard | EURO 5 |
