    Isuzu D-Max

    2016 Isuzu D-Max LS-M HI-RIDE (4x4) Pricing and Spec

    From

    $31,400

    excl. on-roads

    Overview

    The 2016 Isuzu D-Max LS-M HI-RIDE (4x4) is a four-wheel drive crew cab utility that was released to the Australian market on 92nd April 2016 classified as a TF MY15.5. The Isuzu D-Max is regarded as a crew cab utility built in Thailand with prices from a dealer as a used car starting at $31,400.

    The Isuzu D-Max is a four-wheel drive 4 door with 5 seats, powered by a 3.0L DIESEL TURBO 4 engine that has 130 kW of power (at 3600 rpm) and 380 Nm of torque (at 1800 rpm) via a Five-speed Manual. Isuzu claims the D-Max LS-M HI-RIDE (4x4) uses 8.2L/100km of Diesel in the combined city and highway cycle while putting out 217g of CO2. It has a 76L fuel tank, meaning it should be able to travel 927km per full tank.

    The Isuzu D-Max measures 1785mm (70.3 inches) in height, 5295mm (208.5 inches) in length, 1860mm (73.2 inches) in width with a 3095mm (121.9 inches) wheelbase that brings about a total of 1925kg (4243.9 lbs) of unladen weight. The D-Max LS-M HI-RIDE (4x4) comes standard with 245/70 R16 front tyres and 245/70 R16 rear tyres. It requires a service every 6 months or 10,000 km, whichever comes first. It has a 60 month, 130km warranty.

    The 2016 Isuzu D-Max LS-M HI-RIDE (4x4) has a 225mm ground clearance with a 3500kg braked and 750kg unbraked towing capacity. It has a final gear ratio of 3.727.

    The Isuzu D-Max has received a 5 star rating from ANCAP. The VIN number can be found on the Mid Driver Side Chassis and the compliance plate is located on the RHS Corner of Deflector Panel. An example VIN number would be similar to MPATFS85JDT000011.

    Best For
    Work
    Family
    Long distance
    Warranty
    5Years
    or
    130,000 km
    ANCAP Safety Rating
    Fuel Efficiency
    76 L927 km
    CREW CAB UTILITY
    DIESEL
    3.0L
    4x4
    5 MT
    5
    4

    Dimensions

    1785mm
    1860mm
    5295mm

    The dimensions shown above are for the base model.

    Specifications

    TypeTURBO CDI
    Size (cc)2999
    Size (L)3.0L
    InductionDIESEL TURBO 4
    CamshaftDUAL OVERHEAD CAM
    Valves/Ports per Cylinder16
    Power130kW
    Power RPM3600
    Torque380Nm
    Torque RPM1800
    Bore Stroke-
    Compression Ratio17.3

    Transmission5 SP MANUAL
    Final Gear Ratio3.727
    Suspension Front-
    Suspension Rear-
    Steering MechanismRACK & PINION - POWER ASSISTED
    Drive4x4

    Fuel Combined (L/100km)8.2
    Fuel Urban (L/100km)0
    Fuel Extra Urban (L/100km)0
    Tank Size (L)76
    Fuel TypeDIESEL
    e10 Compatibleunknown
    CO2 Combined217
    CO2 Urban-
    CO2 Extra Urban-

    Brake FrontDISC - VENTILATED
    Brake RearDRUM
    Tyre Front245/70 R16
    Tyre Rear245/70 R16
    Front Rim Size7x16
    Rear Rim Size7x16

    Vehicle Height (mm)1785
    Vehicle Length (mm)5295
    Vehicle Width (mm)1860
    Ground Clearance (mm)225
    Wheelbase (mm)3095
    Turning Circle (m)12.6
    Unladen Weight (kg)1925
    Gross Combined Weight (kg)5950
    Gross Vehicle Weight (kg)2950
    Track Front-
    Track Rear-
    Towing Capacity Brake (kg)3500
    Towing Capacity Unbraked (kg)750

    Compliance Plate LocationRHS Corner of Deflector Panel
    Country Of OriginTHAILAND
    Number of Doors4
    Seats5
    Service Interval KMs10
    Service Interval Months6
    VIN LocationMid Driver Side Chassis
    VIN NumberMPATFS85JDT000011
    Warranty KMs130
    Warranty Months60
    Discontinued Date2017-02-28

    ANCAP Rating5
    Euro Air Pollution Standard-
