2017 Jaguar F-Pace 30d Portfolio Awd Pricing and Spec
From
$37,900
excl. on-roads
Overview
The 2017 Jaguar F-pace 30d Portfolio AWD is an all wheel drive 4 Door Wagon that was released to the Australian market on 12th January 2016 classified as a MY17. The Jaguar F-pace is regarded as a SUV medium built in United Kingdom with prices from a dealer as a used car starting at $37,900.
The Jaguar F-pace is an all wheel drive 4 door with 5 seats, powered by a 3.0L Diesel Turbo V6 engine that has 221 kW of power (at 4000 rpm) and 700 Nm of torque (at 2000 rpm) via a 8 Speed Automatic. Jaguar claims the F-Pace 30d Portfolio AWD uses 6.0L/100km of diesel in the combined city and highway cycle while putting out 159g of CO2. It has a 60L fuel tank, meaning it should be able to travel 1000km per full tank.
The Jaguar F-pace measures 1667mm (65.6 inches) in height, 4731mm (186.3 inches) in length, 1936mm (76.2 inches) in width with a 2874mm (113.1 inches) wheelbase that brings about a total of 1838kg (4052.1 lbs) of unladen weight. The F-Pace 30d Portfolio AWD comes standard with 255/55 R19 front tyres and 255/55 R19 rear tyres. It requires a service every 24 months or 25,000 km, whichever comes first. It has a 36 month, 100km warranty.
The 2017 Jaguar F-pace 30d Portfolio AWD has a 207mm ground clearance with a 2400kg braked and 750kg unbraked towing capacity. It has a final gear ratio of 3.230.
The Jaguar F-pace has received a 5 star rating from ANCAP. The VIN number can be found on the Driver Side Inner Guard and the compliance plate is located on the RH Side in Boot Compartment. An example VIN number would be similar to SADCA2AK8HA045124.
Dimensions
The dimensions shown above are for the base model.
Specifications
| Type | Turbo Common Rail Diesel Injection |
|---|---|
| Size (cc) | 2993 |
| Size (L) | - |
| Induction | Diesel Turbo V6 |
| Camshaft | DUAL OVERHEAD CAM |
| Valves/Ports per Cylinder | 24 |
| Power | 221kW |
| Power RPM | 4000 |
| Torque | 700Nm |
| Torque RPM | 2000 |
| Bore Stroke | 84x90 |
| Compression Ratio | 16.10 |
| Transmission | 8 Speed Automatic |
|---|---|
| Final Gear Ratio | 3.230 |
| Suspension Front | macpherson strut |
| Suspension Rear | integral link |
| Steering Mechanism | VARIABLE RATIO RACK & PINION |
| Drive | AWD |
| Fuel Combined (L/100km) | 6.0 |
|---|---|
| Fuel Urban (L/100km) | 6.9 |
| Fuel Extra Urban (L/100km) | 5.6 |
| Tank Size (L) | 60 |
| Fuel Type | diesel |
| e10 Compatible | - |
| CO2 Combined | 159 |
| CO2 Urban | 181 |
| CO2 Extra Urban | 146 |
| Brake Front | DISC - VENTILATED |
|---|---|
| Brake Rear | DISC - VENTILATED |
| Tyre Front | 255/55 R19 |
| Tyre Rear | 255/55 R19 |
| Front Rim Size | 8.5x19 |
| Rear Rim Size | 8.5x19 |
| Vehicle Height (mm) | 1667 |
|---|---|
| Vehicle Length (mm) | 4731 |
| Vehicle Width (mm) | 1936 |
| Ground Clearance (mm) | 207 |
| Wheelbase (mm) | 2874 |
| Turning Circle (m) | 0.0 |
| Unladen Weight (kg) | 1838 |
| Gross Combined Weight (kg) | - |
| Gross Vehicle Weight (kg) | 2570 |
| Track Front | - |
| Track Rear | - |
| Towing Capacity Brake (kg) | 2400 |
| Towing Capacity Unbraked (kg) | 750 |
| Compliance Plate Location | RH Side in Boot Compartment |
|---|---|
| Country Of Origin | United Kingdom |
| Number of Doors | 4 |
| Seats | 5 |
| Service Interval KMs | 25 |
| Service Interval Months | 24 |
| VIN Location | Driver Side Inner Guard |
| VIN Number | SADCA2AK8HA045124 |
| Warranty KMs | 100 |
| Warranty Months | 36 |
| Discontinued Date | 31/05/2017 |
| ANCAP Rating | 5 |
|---|---|
| Euro Air Pollution Standard | Euro 6 |
