Overview
The 2021 Mazda Bt-50 XT (4x4) is a four-wheel drive Cab Chassis that was released to the Australian market on 8th January 2020 classified as a B30B. The Mazda Bt-50 is regarded as a pick up or cab chassis 4x4 built in Thailand with prices from a dealer as a used car starting at $36,800.
The Mazda Bt-50 is a four-wheel drive 2 door with 2 seats, powered by a 3.0L Diesel Turbo 4 Cylinder engine that has 140 kW of power (at 3600 rpm) and 450 Nm of torque (at 1600 rpm) via a 6 Speed Automatic. Mazda claims the BT-50 XT (4x4) uses 8.0L/100km of diesel in the combined city and highway cycle while putting out 207g of CO2. It has a 76L fuel tank, meaning it should be able to travel 950km per full tank.
The Mazda Bt-50 measures 1800mm (70.9 inches) in height, 5320mm (209.4 inches) in length, 1870mm (73.6 inches) in width with a 3125mm (123.0 inches) wheelbase that brings about a total of 1770kg (3902.2 lbs) of unladen weight. The BT-50 XT (4x4) comes standard with 255/65 R17 110S front tyres and 255/65 R17 110S rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first. It has a 60 month, unlimited kilometre warranty.
The 2021 Mazda Bt-50 XT (4x4) has a 235mm ground clearance with a 3500kg braked and 750kg unbraked towing capacity. It has a final gear ratio of 3.416.
The Mazda Bt-50 has received a 5 star rating from ANCAP. The VIN number can be found on the Centre Of Chassis Frame and the compliance plate is located on the Lower Driver Side Centre Pilla. An example VIN number would be similar to MP2TFR40JL*100001.
Dimensions
The dimensions shown above are for the base model.
Specifications
| Type | Turbo Common Rail Diesel Injection |
|---|---|
| Size (cc) | 2999 |
| Size (L) | - |
| Induction | Diesel Turbo 4 Cylinder |
| Camshaft | DUAL OVERHEAD CAM |
| Valves/Ports per Cylinder | 16 |
| Power | 140kW |
| Power RPM | 3600 |
| Torque | 450Nm |
| Torque RPM | 1600 |
| Bore Stroke | 95.4x104.9 |
| Compression Ratio | 16.30 |
| Transmission | 6 Speed Automatic |
|---|---|
| Final Gear Ratio | 3.416 |
| Suspension Front | anti roll bar, coil spring, independent double wishbone |
| Suspension Rear | rigid axle, leaf spring - heavy duty |
| Steering Mechanism | ELECTRIC POWER STEERING |
| Drive | 4x4 |
| Fuel Combined (L/100km) | 8.0 |
|---|---|
| Fuel Urban (L/100km) | 9.8 |
| Fuel Extra Urban (L/100km) | 6.9 |
| Tank Size (L) | 76 |
| Fuel Type | diesel |
| e10 Compatible | - |
| CO2 Combined | 207 |
| CO2 Urban | 254 |
| CO2 Extra Urban | 180 |
| Brake Front | DISC - VENTILATED |
|---|---|
| Brake Rear | DRUM |
| Tyre Front | 255/65 R17 110S |
| Tyre Rear | 255/65 R17 110S |
| Front Rim Size | 7Jx17 |
| Rear Rim Size | 7Jx17 |
| Vehicle Height (mm) | 1800 |
|---|---|
| Vehicle Length (mm) | 5320 |
| Vehicle Width (mm) | 1870 |
| Ground Clearance (mm) | 235 |
| Wheelbase (mm) | 3125 |
| Turning Circle (m) | 12.5 |
| Unladen Weight (kg) | 1770 |
| Gross Combined Weight (kg) | 5950 |
| Gross Vehicle Weight (kg) | 3100 |
| Track Front | - |
| Track Rear | - |
| Towing Capacity Brake (kg) | 3500 |
| Towing Capacity Unbraked (kg) | 750 |
| Compliance Plate Location | Lower Driver Side Centre Pilla |
|---|---|
| Country Of Origin | Thailand |
| Number of Doors | 2 |
| Seats | 2 |
| Service Interval KMs | 15 |
| Service Interval Months | 12 |
| VIN Location | Centre Of Chassis Frame |
| VIN Number | MP2TFR40JL*100001 |
| Warranty KMs | 999 |
| Warranty Months | 60 |
| Discontinued Date | - |
| ANCAP Rating | 5 |
|---|---|
| Euro Air Pollution Standard | EURO 5 |
