Overview
The 2016 Ford Escape TREND (AWD) is an all wheel drive 4 Door Wagon that was released to the Australian market on 12th January 2016 classified as a ZG. The Ford Escape is regarded as a SUV medium built in Spain with prices from a dealer as a used car starting at $14,800.
The Ford Escape is an all wheel drive 4 door with 5 seats, powered by a 2.0L Diesel Turbo 4 Cylinder engine that has 132 kW of power (at 3500 rpm) and 400 Nm of torque (at 2000 rpm) via a 6 Speed Automatic. Ford claims the Escape TREND (AWD) uses 5.5L/100km of diesel in the combined city and highway cycle while putting out 144g of CO2. It has a 60L fuel tank, meaning it should be able to travel 1091km per full tank.
The Ford Escape measures 1713mm (67.4 inches) in height, 4524mm (178.1 inches) in length, 1838mm (72.4 inches) in width with a 2690mm (105.9 inches) wheelbase that brings about a total of 1750kg (3858.1 lbs) of unladen weight. The Escape TREND (AWD) comes standard with 235/50 R18 front tyres and 235/50 R18 rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first. It has a 36 month, 100km warranty.
The 2016 Ford Escape TREND (AWD) has a 163mm ground clearance with a 1500kg braked and 750kg unbraked towing capacity.
The Ford Escape has received a 5 star rating from ANCAP. The VIN number can be found on the Driver Side Front Floor and the compliance plate is located on the Driver Side Centre B-Pillar. An example VIN number would be similar to WF0AXXWPMA%$12345.
Dimensions
The dimensions shown above are for the base model.
Specifications
| Type | Diesel Turbo Fuel Injection |
|---|---|
| Size (cc) | 1998 |
| Size (L) | - |
| Induction | Diesel Turbo 4 Cylinder |
| Camshaft | DUAL OVERHEAD CAM |
| Valves/Ports per Cylinder | 16 |
| Power | 132kW |
| Power RPM | 3500 |
| Torque | 400Nm |
| Torque RPM | 2000 |
| Bore Stroke | 85x88 |
| Compression Ratio | 16.70 |
| Transmission | 6 Speed Automatic |
|---|---|
| Final Gear Ratio | 0.000 |
| Suspension Front | anti roll bar, coil spring, gas damper, macpherson strut |
| Suspension Rear | anti roll bar, multi-link system, coil spring, gas damper |
| Steering Mechanism | RACK & PINION - POWER ASSISTED |
| Drive | AWD |
| Fuel Combined (L/100km) | 5.5 |
|---|---|
| Fuel Urban (L/100km) | - |
| Fuel Extra Urban (L/100km) | - |
| Tank Size (L) | 60 |
| Fuel Type | diesel |
| e10 Compatible | - |
| CO2 Combined | 144 |
| CO2 Urban | - |
| CO2 Extra Urban | - |
| Brake Front | DISC - VENTILATED |
|---|---|
| Brake Rear | DISC |
| Tyre Front | 235/50 R18 |
| Tyre Rear | 235/50 R18 |
| Front Rim Size | 7.5x18 |
| Rear Rim Size | 7.5x18 |
| Vehicle Height (mm) | 1713 |
|---|---|
| Vehicle Length (mm) | 4524 |
| Vehicle Width (mm) | 1838 |
| Ground Clearance (mm) | 163 |
| Wheelbase (mm) | 2690 |
| Turning Circle (m) | 11.1 |
| Unladen Weight (kg) | 1750 |
| Gross Combined Weight (kg) | - |
| Gross Vehicle Weight (kg) | 2230 |
| Track Front | - |
| Track Rear | - |
| Towing Capacity Brake (kg) | 1500 |
| Towing Capacity Unbraked (kg) | 750 |
| Compliance Plate Location | Driver Side Centre B-Pillar |
|---|---|
| Country Of Origin | Spain |
| Number of Doors | 4 |
| Seats | 5 |
| Service Interval KMs | 15 |
| Service Interval Months | 12 |
| VIN Location | Driver Side Front Floor |
| VIN Number | WF0AXXWPMA%$12345 |
| Warranty KMs | 100 |
| Warranty Months | 36 |
| Discontinued Date | 31/10/2017 |
| ANCAP Rating | 5 |
|---|---|
| Euro Air Pollution Standard | - |
