Overview
The 2024 Ford Ranger PLATINUM 3.0 (4x4) is a four wheel drive Double Cab Pick Up that was released to the Australian market on 3rd January 2024 classified as a PY MY24.5. The Ford Ranger is regarded as a pick up or cab chassis 4x4 built in Thailand with prices starting at $80,640 before on-road costs.
The Ford Ranger is a four wheel drive 4 door with 5 seats, powered by a 3.0L Diesel Turbo V6 engine that has 184 kW of power (at 3250 rpm) and 600 Nm of torque (at 1750 rpm) via a 10 Speed Automatic. Ford claims the Ranger PLATINUM 3.0 (4x4) uses 8.4L/100km of diesel in the combined city and highway cycle while putting out 222g of CO2. It has a 80L fuel tank, meaning it should be able to travel 952km per full tank.
The Ford Ranger measures 1920mm (75.6 inches) in height, 5370mm (211.4 inches) in length, 1918mm (75.5 inches) in width with a 3270mm (128.7 inches) wheelbase that brings about a total of 2388kg (5264.6 lbs) of unladen weight. The Ranger PLATINUM 3.0 (4x4) comes standard with 255/55 R20 front tyres and 255/55 R20 rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first. It has a 60 month, unlimited kilometre warranty.
The 2024 Ford Ranger PLATINUM 3.0 (4x4) has a 234mm ground clearance with a 3500kg braked and 750kg unbraked towing capacity.
The Ford Ranger has received a 5 star rating from ANCAP. The VIN number can be found on the Centre Of Chassis Frame and the compliance plate is located on the Lower Driver Side B-Pillar. An example VIN number would be similar to M@*#MF$%0&W123456.
Pros
- Signature ride comfort, refinement
- New V6 diesel, permanent 4WD a great addition
- Enhanced interior ergonomics and displays
Cons
- No manual gearbox option at all
- Extra cabin storage limited to Wildtrak
- Putting 4x4 settings in a touchscreen may not be wise
Dimensions
The dimensions shown above are for the base model.
Specifications
| Type | Turbo Common Rail Diesel Injection |
|---|---|
| Size (cc) | 2990 |
| Size (L) | - |
| Induction | Diesel Turbo V6 |
| Camshaft | VARIABLE DOUBLE OVERHEAD CAM |
| Valves/Ports per Cylinder | 16 |
| Power | 184kW |
| Power RPM | 3250 |
| Torque | 600Nm |
| Torque RPM | 1750 |
| Bore Stroke | - |
| Compression Ratio | 16.00 |
| Transmission | 10 Speed Automatic |
|---|---|
| Final Gear Ratio | 0.000 |
| Suspension Front | not sufficient data |
| Suspension Rear | not sufficient data |
| Steering Mechanism | ELECTRIC POWER STEERING |
| Drive | 4WD |
| Fuel Combined (L/100km) | 8.4 |
|---|---|
| Fuel Urban (L/100km) | 10.0 |
| Fuel Extra Urban (L/100km) | 7.5 |
| Tank Size (L) | 80 |
| Fuel Type | diesel |
| e10 Compatible | - |
| CO2 Combined | 222 |
| CO2 Urban | 265 |
| CO2 Extra Urban | 198 |
| Brake Front | DISC - VENTILATED |
|---|---|
| Brake Rear | DISC - VENTILATED |
| Tyre Front | 255/55 R20 |
| Tyre Rear | 255/55 R20 |
| Front Rim Size | 8Jx20 |
| Rear Rim Size | 8Jx20 |
| Vehicle Height (mm) | 1920 |
|---|---|
| Vehicle Length (mm) | 5370 |
| Vehicle Width (mm) | 1918 |
| Ground Clearance (mm) | 234 |
| Wheelbase (mm) | 3270 |
| Turning Circle (m) | 12.9 |
| Unladen Weight (kg) | 2388 |
| Gross Combined Weight (kg) | 6400 |
| Gross Vehicle Weight (kg) | 3300 |
| Track Front | - |
| Track Rear | - |
| Towing Capacity Brake (kg) | 3500 |
| Towing Capacity Unbraked (kg) | 750 |
| Compliance Plate Location | Lower Driver Side B-Pillar |
|---|---|
| Country Of Origin | Thailand |
| Number of Doors | 4 |
| Seats | 5 |
| Service Interval KMs | 15 |
| Service Interval Months | 12 |
| VIN Location | Centre Of Chassis Frame |
| VIN Number | M@*#MF$%0&W123456 |
| Warranty KMs | 999 |
| Warranty Months | 60 |
| Discontinued Date | - |
| ANCAP Rating | 5 |
|---|---|
| Euro Air Pollution Standard | EURO 5 |
