Overview
The 2021 Hyundai I30 ACTIVE is a front wheel drive 4 Door Sedan that was released to the Australian market on 8th January 2020 classified as a CN7.V1 MY21. The Hyundai I30 is regarded as a small built in Korea with prices from a dealer as a used car starting at $23,400.
The Hyundai I30 is a front wheel drive 4 door with 5 seats, powered by a 2.0L Inline 4 Cylinder engine that has 117 kW of power (at 6200 rpm) and 191 Nm of torque (at 4500 rpm) via a 6 Speed Manual. Hyundai claims the i30 ACTIVE uses 7.0L/100km of unleaded petrol in the combined city and highway cycle while putting out 160g of CO2. It has a 47L fuel tank, meaning it should be able to travel 671km per full tank.
The Hyundai I30 measures 1430mm (56.3 inches) in height, 4650mm (183.1 inches) in length, 1825mm (71.9 inches) in width with a 2720mm (107.1 inches) wheelbase that brings about a total of 1210kg (2667.6 lbs) of unladen weight. The i30 ACTIVE comes standard with 225/45 R17 91W front tyres and 225/45 R17 91W rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first. It has a 60 month, unlimited kilometre warranty.
The 2021 Hyundai I30 ACTIVE has a 140mm ground clearance with a 1200kg braked and 610kg unbraked towing capacity. It has a final gear ratio of 4.188.
The VIN number can be found on the Driver Side Front Floor and the compliance plate is located on the Pass Side Lower A-Pillar. An example VIN number would be similar to KMHLL41GLLU123456.
Pros
- Myriad variants to choose from
- Well-sorted ride and handling
- N versions are proper dynamos
Cons
- Too much tyre noise
- 1.6 turbo's shorter service intervals
- N Line hatches lose some driver-assist features
Dimensions
The dimensions shown above are for the base model.
Specifications
| Type | Multi Point Fuel Injection |
|---|---|
| Size (cc) | 1999 |
| Size (L) | - |
| Induction | Inline 4 Cylinder |
| Camshaft | VARIABLE DOUBLE OVERHEAD CAM |
| Valves/Ports per Cylinder | 16 |
| Power | 117kW |
| Power RPM | 6200 |
| Torque | 191Nm |
| Torque RPM | 4500 |
| Bore Stroke | 81x97 |
| Compression Ratio | 10.80 |
| Transmission | 6 Speed Manual |
|---|---|
| Final Gear Ratio | 4.188 |
| Suspension Front | macpherson strut |
| Suspension Rear | torsion bar |
| Steering Mechanism | RACK & PINION - POWER ASSISTED |
| Drive | FWD |
| Fuel Combined (L/100km) | 7.0 |
|---|---|
| Fuel Urban (L/100km) | 9.4 |
| Fuel Extra Urban (L/100km) | 5.7 |
| Tank Size (L) | 47 |
| Fuel Type | unleaded petrol |
| e10 Compatible | yes |
| CO2 Combined | 160 |
| CO2 Urban | - |
| CO2 Extra Urban | - |
| Brake Front | DISC - VENTILATED |
|---|---|
| Brake Rear | DISC |
| Tyre Front | 225/45 R17 91W |
| Tyre Rear | 225/45 R17 91W |
| Front Rim Size | 7Jx17 +49 |
| Rear Rim Size | 7Jx17 +49 |
| Vehicle Height (mm) | 1430 |
|---|---|
| Vehicle Length (mm) | 4650 |
| Vehicle Width (mm) | 1825 |
| Ground Clearance (mm) | 140 |
| Wheelbase (mm) | 2720 |
| Turning Circle (m) | 10.8 |
| Unladen Weight (kg) | 1210 |
| Gross Combined Weight (kg) | - |
| Gross Vehicle Weight (kg) | 1740 |
| Track Front | - |
| Track Rear | - |
| Towing Capacity Brake (kg) | 1200 |
| Towing Capacity Unbraked (kg) | 610 |
| Compliance Plate Location | Pass Side Lower A-Pillar |
|---|---|
| Country Of Origin | Korea |
| Number of Doors | 4 |
| Seats | 5 |
| Service Interval KMs | 15 |
| Service Interval Months | 12 |
| VIN Location | Driver Side Front Floor |
| VIN Number | KMHLL41GLLU123456 |
| Warranty KMs | 999 |
| Warranty Months | 60 |
| Discontinued Date | - |
| ANCAP Rating | - |
|---|---|
| Euro Air Pollution Standard | EURO 5 |
