    Hyundai Staria

    2022 Hyundai Staria Load 5s 2.2d Liftback Pricing and Spec

    From

    $39,500

    excl. on-roads

    Overview

    The 2022 Hyundai Staria LOAD 5S 2.2D LIFTBACK is a front wheel drive 5 Door Crew Van that was released to the Australian market on 8th January 2021 classified as a US4.V1 MY22. The Hyundai Staria is regarded as a vans/cab chassis 2.5-3.5t built in Korea with prices from a dealer as a used car starting at $39,500.

    The Hyundai Staria is a front wheel drive 5 door with 5 seats, powered by a 2.2L Diesel Turbo 4 Cylinder engine that has 130 kW of power (at 3800 rpm) and 430 Nm of torque (at 1500 rpm) via a 8 Speed Automatic Sequential. Hyundai claims the Staria LOAD 5S 2.2D LIFTBACK uses 7.0L/100km of diesel in the combined city and highway cycle while putting out 183g of CO2. It has a 75L fuel tank, meaning it should be able to travel 1071km per full tank.

    The Hyundai Staria measures 2000mm (78.7 inches) in height, 5253mm (206.8 inches) in length, 1997mm (78.6 inches) in width with a 3273mm (128.9 inches) wheelbase that brings about a total of 2020kg (4453.3 lbs) of unladen weight. The Staria LOAD 5S 2.2D LIFTBACK comes standard with 215/65 R17 108H front tyres and 215/65 R17 108H rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first. It has a 60 month, unlimited kilometre warranty.

    The 2022 Hyundai Staria LOAD 5S 2.2D LIFTBACK has a 186mm ground clearance with a 2500kg braked and 750kg unbraked towing capacity. It has a final gear ratio of 3.320.

    The Hyundai Staria has received a 5 star rating from ANCAP. The VIN number can be found on the Driver Side Front Floor and the compliance plate is located on the Pass Side Lower A-Pillar. An example VIN number would be similar to KMFYAX11LMU000001.

    Best For
    Work
    Long distance
    Transporting
    Warranty
    5Years
    or
    unlimited km
    ANCAP Safety Rating
    Fuel Efficiency
    75 L1071 km
    5 Door Crew Van
    diesel
    2.2L
    FWD
    8 AT
    5
    5

    Dimensions

    2000mm
    1997mm
    5253mm

    The dimensions shown above are for the base model.

    Specifications

    TypeTurbo Common Rail Diesel Injection
    Size (cc)2199
    Size (L)-
    InductionDiesel Turbo 4 Cylinder
    CamshaftDUAL OVERHEAD CAM
    Valves/Ports per Cylinder16
    Power130kW
    Power RPM3800
    Torque430Nm
    Torque RPM1500
    Bore Stroke85.4x96
    Compression Ratio16.00

    Transmission8 Speed Automatic Sequential
    Final Gear Ratio3.320
    Suspension Frontmacpherson strut
    Suspension Rearrigid axle, leaf spring - heavy duty
    Steering MechanismCOLUMN MOUNTED MOTOR DRIVEN PWR STEERING
    DriveFWD

    Fuel Combined (L/100km)7.0
    Fuel Urban (L/100km)8.9
    Fuel Extra Urban (L/100km)5.9
    Tank Size (L)75
    Fuel Typediesel
    e10 Compatible-
    CO2 Combined183
    CO2 Urban233
    CO2 Extra Urban155

    Brake FrontDISC - VENTILATED
    Brake RearDISC - VENTILATED
    Tyre Front215/65 R17 108H
    Tyre Rear215/65 R17 108H
    Front Rim Size6.5Jx17
    Rear Rim Size6.5Jx17

    Vehicle Height (mm)2000
    Vehicle Length (mm)5253
    Vehicle Width (mm)1997
    Ground Clearance (mm)186
    Wheelbase (mm)3273
    Turning Circle (m)11.9
    Unladen Weight (kg)2020
    Gross Combined Weight (kg)5610
    Gross Vehicle Weight (kg)3110
    Track Front-
    Track Rear-
    Towing Capacity Brake (kg)2500
    Towing Capacity Unbraked (kg)750

    Compliance Plate LocationPass Side Lower A-Pillar
    Country Of OriginKorea
    Number of Doors5
    Seats5
    Service Interval KMs15
    Service Interval Months12
    VIN LocationDriver Side Front Floor
    VIN NumberKMFYAX11LMU000001
    Warranty KMs999
    Warranty Months60
    Discontinued Date-

    ANCAP Rating5
    Euro Air Pollution StandardEURO 5
