Overview
The 2021 Mazda Cx-3 MAXX SPORT LE (FWD) is a front wheel drive 4 Door Wagon that was released to the Australian market on 11th January 2020 classified as a CX3F. The Mazda Cx-3 is regarded as a SUV light built in Japan with prices from a dealer as a used car starting at $20,700.
The Mazda Cx-3 is a front wheel drive 4 door with 5 seats, powered by a 2.0L Inline 4 Cylinder engine that has 110 kW of power (at 6000 rpm) and 195 Nm of torque (at 2800 rpm) via a 6 Speed Automatic. Mazda claims the CX-3 MAXX SPORT LE (FWD) uses 6.3L/100km of unleaded petrol in the combined city and highway cycle while putting out 143g of CO2. It has a 48L fuel tank, meaning it should be able to travel 762km per full tank.
The Mazda Cx-3 measures 1535mm (60.4 inches) in height, 4275mm (168.3 inches) in length, 1765mm (69.5 inches) in width with a 2570mm (101.2 inches) wheelbase that brings about a total of 1297kg (2859.4 lbs) of unladen weight. The CX-3 MAXX SPORT LE (FWD) comes standard with 215/60 R16 front tyres and 215/60 R16 rear tyres. It requires a service every 12 months or 10,000 km, whichever comes first. It has a 60 month, unlimited kilometre warranty.
The 2021 Mazda Cx-3 MAXX SPORT LE (FWD) has a 160mm ground clearance with a 1200kg braked and 640kg unbraked towing capacity. It has a final gear ratio of 4.325.
The Mazda Cx-3 has received a 5 star rating from ANCAP. The VIN number can be found on the Driver Side Front Floor and the compliance plate is located on the Lower Pass Side Centre Pillar. An example VIN number would be similar to MM0DK2W7A0W123456.
Dimensions
The dimensions shown above are for the base model.
Specifications
| Type | Direct Fuel Injection |
|---|---|
| Size (cc) | 1998 |
| Size (L) | - |
| Induction | Inline 4 Cylinder |
| Camshaft | VARIABLE DOUBLE OVERHEAD CAM |
| Valves/Ports per Cylinder | 16 |
| Power | 110kW |
| Power RPM | 6000 |
| Torque | 195Nm |
| Torque RPM | 2800 |
| Bore Stroke | 83.5x91.2 |
| Compression Ratio | 13.00 |
| Transmission | 6 Speed Automatic |
|---|---|
| Final Gear Ratio | 4.325 |
| Suspension Front | anti roll bar, coil spring, gas damper, macpherson strut |
| Suspension Rear | anti roll bar, coil spring, gas damper, torsion bar |
| Steering Mechanism | RACK & PINION - POWER ASSISTED |
| Drive | FWD |
| Fuel Combined (L/100km) | 6.3 |
|---|---|
| Fuel Urban (L/100km) | 7.7 |
| Fuel Extra Urban (L/100km) | 5.5 |
| Tank Size (L) | 48 |
| Fuel Type | unleaded petrol |
| e10 Compatible | - |
| CO2 Combined | 143 |
| CO2 Urban | - |
| CO2 Extra Urban | - |
| Brake Front | DISC - VENTILATED |
|---|---|
| Brake Rear | DISC |
| Tyre Front | 215/60 R16 |
| Tyre Rear | 215/60 R16 |
| Front Rim Size | 6.5Jx16 |
| Rear Rim Size | 6.5Jx16 |
| Vehicle Height (mm) | 1535 |
|---|---|
| Vehicle Length (mm) | 4275 |
| Vehicle Width (mm) | 1765 |
| Ground Clearance (mm) | 160 |
| Wheelbase (mm) | 2570 |
| Turning Circle (m) | 10.6 |
| Unladen Weight (kg) | 1297 |
| Gross Combined Weight (kg) | - |
| Gross Vehicle Weight (kg) | - |
| Track Front | - |
| Track Rear | - |
| Towing Capacity Brake (kg) | 1200 |
| Towing Capacity Unbraked (kg) | 640 |
| Compliance Plate Location | Lower Pass Side Centre Pillar |
|---|---|
| Country Of Origin | Japan |
| Number of Doors | 4 |
| Seats | 5 |
| Service Interval KMs | 10 |
| Service Interval Months | 12 |
| VIN Location | Driver Side Front Floor |
| VIN Number | MM0DK2W7A0W123456 |
| Warranty KMs | 999 |
| Warranty Months | 60 |
| Discontinued Date | 31/10/2021 |
| ANCAP Rating | 5 |
|---|---|
| Euro Air Pollution Standard | EURO 5 |
