    Mazda 3

    2014 Mazda 3 MAXX Pricing and Spec

    From

    $11,700

    excl. on-roads

    Overview

    The 2014 Mazda 3 Mazda MAXX is a front-wheel drive five-door hatchback that was released to the Australian market on 244th September 2013 classified as a BM. The Mazda Mazda 3 is regarded as a 5d hatchback built in Japan with prices from a dealer as a used car starting at $11,700.

    The Mazda Mazda 3 is a front-wheel drive 5 door with 5 seats, powered by a 2.0L INLINE 4 engine that has 114 kW of power (at 6000 rpm) and 200 Nm of torque (at 4000 rpm) via a Six-speed Manual. Mazda claims the Mazda 3 MAXX uses 5.9L/100km of Unleaded Petrol in the combined city and highway cycle while putting out 138g of CO2. It has a 51L fuel tank, meaning it should be able to travel 864km per full tank.

    The Mazda Mazda 3 measures 1455mm (57.3 inches) in height, 4460mm (175.6 inches) in length, 1795mm (70.7 inches) in width with a 2700mm (106.3 inches) wheelbase that brings about a total of 1300kg (2866.0 lbs) of unladen weight. The Mazda 3 MAXX comes standard with 205/60 R16 front tyres and 205/60 R16 rear tyres. It requires a service every 12 months or 10,000 km, whichever comes first. It has a 36 month, 100km warranty.

    The 2014 Mazda Mazda 3 MAXX has a 155mm ground clearance with a 1200kg braked and 600kg unbraked towing capacity. It has a final gear ratio of 4.105.

    The Mazda Mazda 3 has received a 5 star rating from ANCAP. The VIN number can be found on the Driver Side Front Floor and the compliance plate is located on the Lower Pass Side Centre Pillar. An example VIN number would be similar to JM0BM547810123456.

    Best For
    City driving
    Warranty
    3Years
    or
    100,000km
    ANCAP Safety Rating
    Fuel Efficiency
    51 L864 km
    5D HATCHBACK
    petrol
    2.0L
    FRONT WHEEL DRIVE
    6 MT
    5
    5

    Dimensions

    1455mm
    1795mm
    4460mm

    The dimensions shown above are for the base model.

    Specifications

    TypeMULTI POINT F/INJ
    Size (cc)1998
    Size (L)2.0L
    InductionINLINE 4
    CamshaftVARIABLE DOUBLE OVERHEAD CAM
    Valves/Ports per Cylinder16
    Power114kW
    Power RPM6000
    Torque200Nm
    Torque RPM4000
    Bore Stroke-
    Compression Ratio13

    Transmission6 SP MANUAL
    Final Gear Ratio4.105
    Suspension Front-
    Suspension Rear-
    Steering MechanismRACK & PINION - POWER ASSISTED
    DriveFRONT WHEEL DRIVE

    Fuel Combined (L/100km)5.9
    Fuel Urban (L/100km)7.6
    Fuel Extra Urban (L/100km)4.9
    Tank Size (L)51
    Fuel TypeUNLEADED PETROL
    e10 Compatibleunknown
    CO2 Combined138
    CO2 Urban178
    CO2 Extra Urban116

    Brake FrontDISC - VENTILATED
    Brake RearDISC
    Tyre Front205/60 R16
    Tyre Rear205/60 R16
    Front Rim Size6.5x16
    Rear Rim Size6.5x16

    Vehicle Height (mm)1455
    Vehicle Length (mm)4460
    Vehicle Width (mm)1795
    Ground Clearance (mm)155
    Wheelbase (mm)2700
    Turning Circle (m)10.6
    Unladen Weight (kg)1300
    Gross Combined Weight (kg)0
    Gross Vehicle Weight (kg)0
    Track Front-
    Track Rear-
    Towing Capacity Brake (kg)1200
    Towing Capacity Unbraked (kg)600

    Compliance Plate LocationLower Pass Side Centre Pillar
    Country Of OriginJAPAN
    Number of Doors5
    Seats5
    Service Interval KMs10
    Service Interval Months12
    VIN LocationDriver Side Front Floor
    VIN NumberJM0BM547810123456
    Warranty KMs100
    Warranty Months36
    Discontinued Date2015-01-31

    ANCAP Rating5
    Euro Air Pollution StandardEuro 5
