Overview
The 2014 Toyota Prius V i-TECH HYBRID is a front wheel drive 4 Door Wagon that was released to the Australian market on 12th January 2012 classified as a ZVW40R. The Toyota Prius V is regarded as a small built in Japan with prices from a dealer as a used car starting at $23,100.
The Toyota Prius V is a front wheel drive 4 door with 7 seats, powered by a 1.8L Inline 4 Cylinder engine that has 73 kW of power (at 5200 rpm) and 142 Nm of torque (at 4000 rpm) via a Continuous Variable. Toyota claims the Prius V i-TECH HYBRID uses 4.4L/100km of unleaded petrol/electric in the combined city and highway cycle while putting out 101g of CO2. It has a 45L fuel tank, meaning it should be able to travel 1023km per full tank.
The Toyota Prius V measures 1615mm (63.6 inches) in height, 4615mm (181.7 inches) in length, 1775mm (69.9 inches) in width with a 2780mm (109.4 inches) wheelbase that brings about a total of 1565kg (3450.2 lbs) of unladen weight. The Prius V i-TECH HYBRID comes standard with 205/60 R16 front tyres and 205/60 R16 rear tyres. It requires a service every 6 months or 10,000 km, whichever comes first. It has a 36 month, 100km warranty.
The 2014 Toyota Prius V i-TECH HYBRID has a 160mm ground clearance It has a final gear ratio of 3.703.
The Toyota Prius V has received a 5 star rating from ANCAP. The VIN number can be found on the Driver Side Front Floor and the compliance plate is located on the Pass Side Centre B-Pillar. An example VIN number would be similar to JTDZS3EU200123456.
Dimensions
The dimensions shown above are for the base model.
Specifications
| Type | Multi Point Fuel Injection |
|---|---|
| Size (cc) | 1798 |
| Size (L) | - |
| Induction | Inline 4 Cylinder |
| Camshaft | VARIABLE DOUBLE OVERHEAD CAM |
| Valves/Ports per Cylinder | 16 |
| Power | 73kW |
| Power RPM | 5200 |
| Torque | 142Nm |
| Torque RPM | 4000 |
| Bore Stroke | 80.5x88.3 |
| Compression Ratio | 13.00 |
| Transmission | Continuous Variable |
|---|---|
| Final Gear Ratio | 3.703 |
| Suspension Front | anti roll bar, coil spring, gas damper, macpherson strut |
| Suspension Rear | anti roll bar, coil spring, gas damper, torsion bar |
| Steering Mechanism | RACK & PINION - POWER ASSISTED |
| Drive | FWD |
| Fuel Combined (L/100km) | 4.4 |
|---|---|
| Fuel Urban (L/100km) | - |
| Fuel Extra Urban (L/100km) | - |
| Tank Size (L) | 45 |
| Fuel Type | unleaded petrol/electric |
| e10 Compatible | - |
| CO2 Combined | 101 |
| CO2 Urban | 100 |
| CO2 Extra Urban | 96 |
| Brake Front | DISC - VENTILATED |
|---|---|
| Brake Rear | DISC |
| Tyre Front | 205/60 R16 |
| Tyre Rear | 205/60 R16 |
| Front Rim Size | 6.5x16 |
| Rear Rim Size | 6.5x16 |
| Vehicle Height (mm) | 1615 |
|---|---|
| Vehicle Length (mm) | 4615 |
| Vehicle Width (mm) | 1775 |
| Ground Clearance (mm) | 160 |
| Wheelbase (mm) | 2780 |
| Turning Circle (m) | 11.0 |
| Unladen Weight (kg) | 1565 |
| Gross Combined Weight (kg) | - |
| Gross Vehicle Weight (kg) | 2115 |
| Track Front | - |
| Track Rear | - |
| Towing Capacity Brake (kg) | - |
| Towing Capacity Unbraked (kg) | - |
| Compliance Plate Location | Pass Side Centre B-Pillar |
|---|---|
| Country Of Origin | Japan |
| Number of Doors | 4 |
| Seats | 7 |
| Service Interval KMs | 10 |
| Service Interval Months | 6 |
| VIN Location | Driver Side Front Floor |
| VIN Number | JTDZS3EU200123456 |
| Warranty KMs | 100 |
| Warranty Months | 36 |
| Discontinued Date | 31/05/2015 |
| ANCAP Rating | 5 |
|---|---|
| Euro Air Pollution Standard | - |
