Overview
The 2013 Volkswagen Caddy EDITION 30 is a front wheel drive 5 Door Wagon that was released to the Australian market on 10th January 2012 classified as a 2K MY13. The Volkswagen Caddy is regarded as a people movers built in Germany with prices from a dealer as a used car starting at $15,300.
The Volkswagen Caddy is a front wheel drive 5 door with 5 seats, powered by a 2.0L Diesel Turbo 4 Cylinder engine that has 103 kW of power (at 4200 rpm) and 320 Nm of torque (at 1500 rpm) via a 6 Speed Auto Direct Shift. Volkswagen claims the Caddy EDITION 30 uses 6.5L/100km of diesel in the combined city and highway cycle while putting out 166g of CO2. It has a 60L fuel tank, meaning it should be able to travel 923km per full tank.
The Volkswagen Caddy measures 1822mm (71.7 inches) in height, 4436mm (174.6 inches) in length, 1794mm (70.6 inches) in width with a 2681mm (105.6 inches) wheelbase that brings about a total of 1490kg (3284.9 lbs) of unladen weight. The Caddy EDITION 30 comes standard with 205/50 R17 front tyres and 205/50 R17 rear tyres. It requires a service every 15 months or 15,000 km, whichever comes first. It has a 36 month, unlimited kilometre warranty.
The 2013 Volkswagen Caddy EDITION 30 has a 156mm ground clearance with a 1300kg braked and 710kg unbraked towing capacity.
The Volkswagen Caddy has received a 4 star rating from ANCAP. The VIN number can be found on the Drive Side Luggage Compartment and the compliance plate is located on the On C-Pillar Behind LH Door. An example VIN number would be similar to WV2ZZZ2KZBX123456.
Dimensions
The dimensions shown above are for the base model.
Specifications
| Type | Diesel Turbo Fuel Injection |
|---|---|
| Size (cc) | 1968 |
| Size (L) | - |
| Induction | Diesel Turbo 4 Cylinder |
| Camshaft | DUAL OVERHEAD CAM |
| Valves/Ports per Cylinder | 16 |
| Power | 103kW |
| Power RPM | 4200 |
| Torque | 320Nm |
| Torque RPM | 1500 |
| Bore Stroke | 95.5x81 |
| Compression Ratio | 16.00 |
| Transmission | 6 Speed Auto Direct Shift |
|---|---|
| Final Gear Ratio | 0.000 |
| Suspension Front | coil spring, gas damper, macpherson strut |
| Suspension Rear | leaf spring, hydraulic double acting shock absorber |
| Steering Mechanism | RACK & PINION - POWER ASSISTED |
| Drive | FWD |
| Fuel Combined (L/100km) | 6.5 |
|---|---|
| Fuel Urban (L/100km) | - |
| Fuel Extra Urban (L/100km) | - |
| Tank Size (L) | 60 |
| Fuel Type | diesel |
| e10 Compatible | - |
| CO2 Combined | 166 |
| CO2 Urban | - |
| CO2 Extra Urban | - |
| Brake Front | DISC - VENTILATED |
|---|---|
| Brake Rear | DISC |
| Tyre Front | 205/50 R17 |
| Tyre Rear | 205/50 R17 |
| Front Rim Size | 6x17 |
| Rear Rim Size | 6x17 |
| Vehicle Height (mm) | 1822 |
|---|---|
| Vehicle Length (mm) | 4436 |
| Vehicle Width (mm) | 1794 |
| Ground Clearance (mm) | 156 |
| Wheelbase (mm) | 2681 |
| Turning Circle (m) | 11.1 |
| Unladen Weight (kg) | 1490 |
| Gross Combined Weight (kg) | - |
| Gross Vehicle Weight (kg) | 2190 |
| Track Front | - |
| Track Rear | - |
| Towing Capacity Brake (kg) | 1300 |
| Towing Capacity Unbraked (kg) | 710 |
| Compliance Plate Location | On C-Pillar Behind LH Door |
|---|---|
| Country Of Origin | Germany |
| Number of Doors | 5 |
| Seats | 5 |
| Service Interval KMs | 15 |
| Service Interval Months | 15 |
| VIN Location | Drive Side Luggage Compartment |
| VIN Number | WV2ZZZ2KZBX123456 |
| Warranty KMs | 999 |
| Warranty Months | 36 |
| Discontinued Date | 31/01/2014 |
| ANCAP Rating | 4 |
|---|---|
| Euro Air Pollution Standard | - |
