2017 Volkswagen Tiguan 140 Tdi Highline Pricing and Spec
From
$25,100
excl. on-roads
Overview
The 2017 Volkswagen Tiguan 140 TDI HIGHLINE is an all wheel drive 4 Door Wagon that was released to the Australian market on 8th January 2017 classified as a 5NA MY18. The Volkswagen Tiguan is regarded as a SUV medium built in Germany with prices from a dealer as a used car starting at $25,100.
The Volkswagen Tiguan is an all wheel drive 4 door with 5 seats, powered by a 2.0L Turbo 4 Cylinder engine that has 140 kW of power (at 3500 rpm) and 400 Nm of torque (at 1900 rpm) via a 7 Speed Auto Direct Shift. Volkswagen claims the Tiguan 140 TDI HIGHLINE uses 5.9L/100km of diesel in the combined city and highway cycle while putting out 155g of CO2. It has a 60L fuel tank, meaning it should be able to travel 1017km per full tank.
The Volkswagen Tiguan measures 1658mm (65.3 inches) in height, 4486mm (176.6 inches) in length, 1839mm (72.4 inches) in width with a 2681mm (105.6 inches) wheelbase that brings about a total of 1600kg (3527.4 lbs) of unladen weight. The Tiguan 140 TDI HIGHLINE comes standard with 235/55 R18 front tyres and 235/55 R18 rear tyres. It requires a service every 12 months or 15,000 km, whichever comes first. It has a 36 month, unlimited kilometre warranty.
The 2017 Volkswagen Tiguan 140 TDI HIGHLINE has a 201mm ground clearance with a 2500kg braked and 750kg unbraked towing capacity.
The Volkswagen Tiguan has received a 5 star rating from ANCAP. The VIN number can be found on the Driver Side Inner Guard and the compliance plate is located on the RH Door Apert. on Lower B-Pill. An example VIN number would be similar to VWGZZZ5NZ#W123456.
Pros
- Polished road manners
- Strong engines
- Well-packaged interior
Cons
- Optioned-up pricing
- Servicing still not the cheapest
- Rivals are gaining ground
Dimensions
The dimensions shown above are for the base model.
Specifications
| Type | Diesel Turbo Fuel Injection |
|---|---|
| Size (cc) | 1968 |
| Size (L) | - |
| Induction | Turbo 4 Cylinder |
| Camshaft | DUAL OVERHEAD CAM |
| Valves/Ports per Cylinder | 16 |
| Power | 140kW |
| Power RPM | 3500 |
| Torque | 400Nm |
| Torque RPM | 1900 |
| Bore Stroke | 81x95.5 |
| Compression Ratio | 16.20 |
| Transmission | 7 Speed Auto Direct Shift |
|---|---|
| Final Gear Ratio | 0.000 |
| Suspension Front | anti roll bar, macpherson strut, independent, lower arm |
| Suspension Rear | anti roll bar, coil spring, independent, 4 links |
| Steering Mechanism | RACK & PINION - POWER ASSISTED |
| Drive | AWD |
| Fuel Combined (L/100km) | 5.9 |
|---|---|
| Fuel Urban (L/100km) | 6.7 |
| Fuel Extra Urban (L/100km) | 5.4 |
| Tank Size (L) | 60 |
| Fuel Type | diesel |
| e10 Compatible | - |
| CO2 Combined | 155 |
| CO2 Urban | 176 |
| CO2 Extra Urban | 142 |
| Brake Front | DISC - VENTILATED |
|---|---|
| Brake Rear | DISC |
| Tyre Front | 235/55 R18 |
| Tyre Rear | 235/55 R18 |
| Front Rim Size | 7x18 |
| Rear Rim Size | 7x18 |
| Vehicle Height (mm) | 1658 |
|---|---|
| Vehicle Length (mm) | 4486 |
| Vehicle Width (mm) | 1839 |
| Ground Clearance (mm) | 201 |
| Wheelbase (mm) | 2681 |
| Turning Circle (m) | 11.5 |
| Unladen Weight (kg) | 1600 |
| Gross Combined Weight (kg) | - |
| Gross Vehicle Weight (kg) | - |
| Track Front | - |
| Track Rear | - |
| Towing Capacity Brake (kg) | 2500 |
| Towing Capacity Unbraked (kg) | 750 |
| Compliance Plate Location | RH Door Apert. on Lower B-Pill |
|---|---|
| Country Of Origin | Germany |
| Number of Doors | 4 |
| Seats | 5 |
| Service Interval KMs | 15 |
| Service Interval Months | 12 |
| VIN Location | Driver Side Inner Guard |
| VIN Number | VWGZZZ5NZ#W123456 |
| Warranty KMs | 999 |
| Warranty Months | 36 |
| Discontinued Date | 28/02/2018 |
| ANCAP Rating | 5 |
|---|---|
| Euro Air Pollution Standard | EURO 6 |
