    Toyota HiLux

    2013 Toyota HiLux SR (4x4) Pricing and Spec

    From

    $21,600

    excl. on-roads

    Overview

    The 2013 Toyota HiLux SR (4x4) is a four-wheel drive x cab cab chassis that was released to the Australian market on 244th September 2011 classified as a KUN26R MY12. The Toyota HiLux is regarded as a x cab c/chas built in Thailand with prices from a dealer as a used car starting at $21,600.

    The Toyota HiLux is a four-wheel drive 2 door with 4 seats, powered by a 3.0L DIESEL TURBO 4 engine that has 126 kW of power (at 3600 rpm) and 343 Nm of torque (at 1400 rpm) via a Five-speed Manual. Toyota claims the HiLux SR (4x4) uses 8.2L/100km of Diesel in the combined city and highway cycle while putting out 217g of CO2. It has a 76L fuel tank, meaning it should be able to travel 927km per full tank.

    The Toyota HiLux measures 1835mm (72.2 inches) in height, 5135mm (202.2 inches) in length, 1760mm (69.3 inches) in width with a 3085mm (121.5 inches) wheelbase that brings about a total of 1770kg (3902.2 lbs) of unladen weight. The HiLux SR (4x4) comes standard with 205 R16 front tyres and 205 R16 rear tyres. It requires a service every 6 months or 10,000 km, whichever comes first. It has a 36 month, 100km warranty.

    The 2013 Toyota HiLux SR (4x4) has a 215mm ground clearance with a 2500kg braked and 750kg unbraked towing capacity. It has a final gear ratio of 3.583.

    The Toyota HiLux has received a 4 star rating from ANCAP. The VIN number can be found on the Rear Driver Side Chassis and the compliance plate is located on the Lower Pass Side Centre Pillar. An example VIN number would be similar to MR0HZ22G100123456.

    Best For
    Work
    Family
    Long distance
    Awards
    '23
    Ute of the Year
    Best Ute Dyno
    Warranty
    3Years
    or
    100,000 km
    ANCAP Safety Rating
    Fuel Efficiency
    76 L927 km
    X CAB C/CHAS
    DIESEL
    3.0L
    4x4
    5 MT
    4
    2

    Dimensions

    1835mm
    1760mm
    5135mm

    The dimensions shown above are for the base model.

    Specifications

    TypeDIESEL TURBO F/INJ
    Size (cc)2982
    Size (L)3.0L
    InductionDIESEL TURBO 4
    CamshaftDUAL OVERHEAD CAM
    Valves/Ports per Cylinder16
    Power126kW
    Power RPM3600
    Torque343Nm
    Torque RPM1400
    Bore Stroke-
    Compression Ratio17.9

    Transmission5 SP MANUAL
    Final Gear Ratio3.583
    Suspension Front-
    Suspension Rear-
    Steering MechanismRACK & PINION - POWER ASSISTED
    Drive4x4

    Fuel Combined (L/100km)8.2
    Fuel Urban (L/100km)0
    Fuel Extra Urban (L/100km)0
    Tank Size (L)76
    Fuel TypeDIESEL
    e10 Compatibleunknown
    CO2 Combined217
    CO2 Urban-
    CO2 Extra Urban-

    Brake FrontDISC - VENTILATED
    Brake RearDRUM
    Tyre Front205 R16
    Tyre Rear205 R16
    Front Rim Size6x16
    Rear Rim Size6x16

    Vehicle Height (mm)1835
    Vehicle Length (mm)5135
    Vehicle Width (mm)1760
    Ground Clearance (mm)215
    Wheelbase (mm)3085
    Turning Circle (m)12.4
    Unladen Weight (kg)1770
    Gross Combined Weight (kg)0
    Gross Vehicle Weight (kg)2710
    Track Front-
    Track Rear-
    Towing Capacity Brake (kg)2500
    Towing Capacity Unbraked (kg)750

    Compliance Plate LocationLower Pass Side Centre Pillar
    Country Of OriginTHAILAND
    Number of Doors2
    Seats4
    Service Interval KMs10
    Service Interval Months6
    VIN LocationRear Driver Side Chassis
    VIN NumberMR0HZ22G100123456
    Warranty KMs100
    Warranty Months36
    Discontinued Date2014-01-31

    ANCAP Rating4
    Euro Air Pollution Standard-
